Green Series 2 (GT2)
Product Model
GT2070HE
Add comparison
Cancel comparison
GT2100E
Add comparison
Cancel comparison
GT2101E
Add comparison
Cancel comparison
GT2121E2
Add comparison
Cancel comparison
GT2150E2
Add comparison
Cancel comparison
GT2156E-WIFI
Add comparison
Cancel comparison
Slide to display more
Display
Fold up
Expand
Display Size
7"
10.1"
10.1"
12.1"
15"
15.6"
Display Area (W x H)
154.21 x 85.92 mm
222.72 x 125.28 mm
222.72 x 125.28 mm
261.12 x 163.20 mm
304.1 x 228.1 mm
344.16 x 193.59 mm
Resolution
1024*600
1024*600
1024*600
1280*800
1024*768
1920*1080
Colors
16.7 million
16.7 million
16.7 million
16.7 million
16.7 million
65535
Viewing Angle (T/B/L/R)
50/70/70/70
50/70/70/70
50/70/70/70
50/70/70/70
60/70/70/70
85/85/89/89
Contrast Ratio
500:1
500:1
500:1
1200:1
2500:1
800:1
Backlight
LED
LED
LED
LED
LED
LED
Brightness
300 cd/m²
300 cd/m²
400 cd/m²
400 cd/m²
350 cd/m²
250 cd/m²
Backlight Life Time
30000 hours
30000 hours
30000 hours
50000 hours
70000 hours
30000 hours
Touch Panel
Fold up
Expand
Touch Panel
4-wire resistive type
4-wire resistive type
4-wire resistive type
4-wire resistive type
4-wire resistive type
4-wire resistive type
Processor
Fold up
Expand
CPU
Quad-core ARM 1.5GHz
Quad-core ARM 1.5GHz
Quad-core ARM 1.5GHz
Quad-core ARM 1.5GHz
Quad-core ARM 1.5GHz
Quad-core ARM 1.5GHz
GPU
-
-
-
-
-
-
NPU
-
-
-
-
-
-
Memory
Fold up
Expand
RAM
512M
512M
512M
512M
512M
512M
Flash Memory
4GB
4GB
4GB
4GB
4GB
4GB
Interfaces
Fold up
Expand
USB Host
1
1
1
1
1
1
USB Slave
1
1
1
1
1
1
Ethernet
1
1
1
2
2
1
Communication Port
COM0:RS232/RS485/RS422;
COM1:RS485/RS422;
COM2:RS232
COM0:RS232/RS485/RS422;
COM1:RS485
COM2:RS232
COM0:RS232/RS485/RS422;
COM1:RS485/RS422;
COM2:RS232
COM0:RS232/RS485/RS422;
COM1:RS485/RS422;
COM2:RS232
COM0:RS232/RS485/RS422;
COM1:RS485/RS422;
COM2:RS232
COM0:RS232/RS485/RS422;
COM2:RS232
4G
-
-
-
-
-
-
Wi-Fi
-
-
-
-
-
IEE802.11 b/g/n
Audio Interface
-
-
-
-
-
-
Other Interfaces
-
-
-
-
-
-
HDMI
-
-
-
-
-
-
RFID
-
-
-
-
-
-
Programmable Keys
-
-
-
-
-
-
Selector Switch
-
-
-
-
-
-
Emergenccy Stop
-
-
-
-
-
-
Grip Switch
-
-
-
-
-
-
LED Indicator
-
-
-
-
-
-
Electrical
Fold up
Expand
Input Power
DC18V-28V
DC18V-28V
DC18V-28V
DC18V-28V
DC18V-28V
DC18V-28V
Power Consumption
7W@24VDC
7W@24VDC
7W@24VDC
15W@24VDC
15W@24VDC
15W@24VDC
Voltage Interruption Immunity
<3ms
<3ms
<3ms
<3ms
<3ms
<3ms
Insulation Resistance
>50 MΩ @ 500V DC
>50 MΩ @ 500V DC
>50 MΩ @ 500V DC
>50 MΩ @ 500V DC
>50 MΩ @ 500V DC
>50 MΩ @ 500V DC
Dielectric Resistance
500V AC 1minute
500V AC 1minute
500V AC 1minute
500V AC 1minute
500V AC 1minute
500V AC 1minute
Mechanical
Fold up
Expand
Enclosure
Engineering plastic
Engineering plastic
Engineering plastic
Engineering plastic
Engineering plastic
Metal
Dimensions (W x H x D)
204 x 150 x 37 mm
280 x 193 x 36 mm
271 x 213 x 38 mm
309 x 229 x 43 mm
398 x 298 x 47 mm
395 x 259 x 25.5 mm
Cut-out Dimensions
192 x 138 mm
260 x 179 mm
260 x 202 mm
299 x 219 mm
383 x 283 mm
382 x 246 mm
Mounting
Panel mounting
Panel mounting
Panel mounting
Panel mounting
Panel mounting
Panel mounting & Bracket mounting (100*100)
Cable
-
-
-
-
-
-
Mounting Accessories
-
-
-
-
-
-
Environmental
Fold up
Expand
Operating Temperature
0~50°C
0~50°C
0~50°C
0~50°C
0~50°C
0~50°C
Operating Humidity
10~90%RH (Non-condensing)
10~90%RH (Non-condensing)
10~90%RH (Non-condensing)
10~90%RH (Non-condensing)
10~90%RH (Non-condensing)
10~90%RH (Non-condensing)
Storage Temperature
-20~60°C
-20~60°C
-20~60°C
-20~60°C
-20~60°C
-20~60°C
Storage Humidity
10~90%RH (Non-condensing)
10~90%RH (Non-condensing)
10~90%RH (Non-condensing)
10~90%RH (Non-condensing)
10~90%RH (Non-condensing)
10~90%RH (Non-condensing)
Vibration Resistance
10-500Hz, 30m/s², 1 hour each for X, Y, Z directions
10-500Hz, 30m/s², 1 hour each for X, Y, Z directions
10-500Hz, 30m/s², 1 hour each for X, Y, Z directions
10-500Hz, 30m/s², 1 hour each for X, Y, Z directions
10-500Hz, 30m/s², 1 hour each for X, Y, Z directions
10-500Hz, 30m/s², 1 hour each for X, Y, Z directions
Cooling Method
Natural air circulation
Natural air circulation
Natural air circulation
Natural air circulation
Natural air circulation
Natural air circulation
Protection
Fold up
Expand
Power Isolation
-
-
-
Yes
Yes
Yes
Serial Port Isolation
-
-
-
-
-
-
PCB Coating
-
-
-
-
-
-
Protection Grade
Front panel: IP65
Front panel: IP65
Front panel: IP65
Front panel: IP65
Front panel: IP65
Front panel: IP65
Certifications
Fold up
Expand
CE Certificate
EN61000-6-4:2019，EN61000-6-2:2019
EN61000-6-4:2019，EN61000-6-2:2019
EN61000-6-4:2019，EN61000-6-2:2019
EN61000-6-4:2019，EN61000-6-2:2019
EN61000-6-4:2019，EN61000-6-2:2019
EN61000-6-4:2019，EN61000-6-2:2019
UL Certificate
-
-
-
-
-
-
Software
Fold up
Expand
Configuration Software
Kinco DTools
Kinco DTools
Kinco DTools
Kinco DTools
Kinco DTools
Kinco DTools
Remote Maintenance Platform
-
EdgeAccess1.0
-
EdgeAccess1.0
EdgeAccess1.0
EdgeAccess1.0
